Asbestos Free(AF) Fibre Jointing Sheets – AF160 Acid
Asbestos Free(AF) Fibre Jointing Sheets – AF160 Acid
Asbestos Free(AF) Fibre Jointing Sheets – AF160 Acid
A top quality acid resistant compressed synthetic Aramid fibre jointing sheet bonded with special binders
Colour: Cream
Service Conditions
Acid resistant grade. Recommended for use against hot, Concentrated organic/inorganic/mineral acids.
MAX. OPERATING PRESSURE150 barsMAX. SHORT TERM SERVICE TEMP.250 oCMAX. CONTINUOUS SERVICE TEMP.210 oCMAX. OPERATION TEMP. FOR STEAM210 oC
Typical Physical Properties
| Density | – | 1.8 g/cm3 |
| Tensile Strength | ASTM F 152 | 10 Mpa |
| Compressibility | ASTM F 36 | 8% |
| Residual Stress | BS 7531 | 25 Mpa |
| Gas Permeability | BS 7531 | <0.1 cc/Min |
| Recovery | ASTM F 36 | ≥50% |
| Water Absorpation | BS 7531 | ≤5% |
| Ignition Loss | – | ≤35% |
